APC NetShelter SX 42u Enclosure White #AR3150W

Designed for enhanced structural stability. 750mm Wide x 1070mm


Overview

A proven frame design, heavy-gauge mounting rails, and heavy-duty casters provide for 3000 lb (1364 kg) static (levelling feet) and 2250 lb (1023 kg) dynamic (castor) load ratings.

Enclosures have been tested and approved to be combined with proper bolt down accessories to meet various seismic requirements. The roof, side panels and front and rear doors are grounded to the frame of the enclosure. Eight additional electrical grounding inserts are located on the frame for external grounding.

Specifications

  • Physical
  • Maximum Height 78.39 inches ( 1991 , 199.1 cm ) Maximum Width 29.53 inches ( 750 , 75.0 cm ) Maximum Depth 42.13 inches ( 1070 , 107.0 cm ) Rack Height 42 U Net Weight 343.1 lbs. ( 155.63 kg ) Shipping weight 370.0 lbs. ( 167.83 kg ) Shipping Height 87.26 inches ( 2216 , 221.6 cm ) Shipping Width 35.24 inches ( 895 , 89.5 cm ) Shipping Depth 48.0 inches ( 1219 , 121.9 cm ) Color White Maximum Mounting Depth 36.02 inches ( 915.0 , 91.49 cm ) Minimum Mounting Depth 10.31 inches Front Door 16.0 gauge Vertical Posts 16.0 gauge Rear Door 16.0 gauge Roof 18.0 gauge Side Panels 18.0 gauge Units per Pallet 1.0 Rack Width 19" Weight Capacity (dynamic load) 2250.0 lbs. ( 1022.73 kg ) Weight Capacity (static load) 3000.0 lbs. ( 1363.64 kg )
  • Environmental
  • Protection Class IP 20
  • Conformance
  • Approvals UL 2416, UL 60950-1 Standard warranty 5 year repair or replace
  • Sustainable Offer Status
  • RoHS Compliant REACH REACH: Contains No SVHCs PEP Available in Documentation tab EOLI Available in Documentation tab ts_other_compliance_info China RoHS

    • Additional Info
    Accessories
    Warranty Info
