Knurr DI-STRIP 24-Outlets 2.8kW PDU- ( # 035351081)
Twenty-four NEMA 5-20R ("t-slot") receptacles, 30amp L5-30P locking input, 10 ft (3.0m) length cord
Overview
The Knurr DI-STRIP 035351081 is a Basic Rack PDU with (24) NEMA 5-20R ("t-slot") receptacles, 30amp L5-30P locking input. Knurr DI-STRIP Rack PDU meets a broad range of power distribution requirements for IT and other applications. These basic models offer output distribution in a robust package.
Knurr DI-STRIP is designed especially to handle the growing number of electronic components that can be housed within network cabinets and server racks, the space saving product line is available with a range of capabilities to support critical network equipment. This Rack PDU includes an input power cord with appropriate input plug connection and branch protection; basic rack mounting provisions are also provided
Knurr 035351081 Features:
• Flexibility:
• Multiple configurations and input power options available, including international compatibility.
• The addition of the Basic Rack PDU Expansion Unit allows for growth.
• 3m power supply cable offers room for movement.
• Higher Availability
• Reliable and robust solution.
• Worldwide approvals and certification.
• Full-length brass busbar on Standard models enhances operational reliability.
• Standard system extruded casing, and High-Power system heavy duty casing provide durability.
• Lowest Total Cost of Ownership
• Simple and quick installation on the rack’s extrusion requires minimal space and reduces installation time.
Specifications
Knurr 035351081 Specifications:
Mechanical
Height 43.2 in. (1097 mm.)
Width 1.7 in. (44 mm.)
Depth 3.3 in. (85 mm.)
Form Factor Vertical
Shipping Weight 16 lbs. (7 kg.)
Environmental
Operating Temperature 32°F ─ 131°F (0°C ─ 55°C) for altitudes 6,500 ft (2000 meters) above sea level.
Storage Temperature 4°F ─ 140°F (-20°C ─ 60°C)
Relative Humidity 5 ─ 95% non-condensing, non-corrosive
Altitude 6500 ft (2,000 m max.), without power derating when operated within the temperature specified.
Electrostatic Discharge The units are able to withstand an electrostatic discharge compliant to EN61326-1, EN61000-3-2, EN61000-3-3
Input
Voltage 120
Rated Amps 30
Max Continuous Amps 24
kW* 2.8
Phase 1
Plug NEMA L5-30
Input Cord Length 10 ft. (3 m.)
Output
Receptacle/Socket Configuration (24) NEMA 5-20 T-Slot
Warranty 2 Years
Standards CSA tested to UL 60950-1 Information Technology Equipment ROHS Compliant
Notes:
Formulas used to calculate the kW:
=========================
For single-phase: input voltage x max continuous amps = watts
For three-phase: input voltage x max continuous amps x 1.73 = watts
